The SUB 18-AS is a portable 18″ high-power active subwoofer for live sound applications. It features a state-of-the-art transducer and a powerful 2200 Watts Class-D amplifier that delivers sound pressure levels up to 135 dB with exceptional headroom. Designed as the ideal complement for 10″, 12″ or 15″ loudspeakers, it includes Bass Motion Control algorithm for extended bass response at any volume. The connection panel features mono/stereo Combo inputs, an XLR stereo link, and XLR crossover outputs. Rear panel controls include volume, polarity, and low-pass frequency selection. The rugged all-wood cabinet with scratch-resistant polyurea coating makes it durable, easy to carry and install securely. With its versatility, sound quality, and high power output, the SUB 18-AS is perfect for small to mid-sized venues and portable applications.
Specifications
Acoustical specificationsFrequency Response35 Hz – 400 HzMax SPL @ 1m135 dBTransducersWoofer1 x 18”, 4.0” v.cInput/Output sectionInput signalbal/unbalInput connectorsCombo XLR/JackOutput connectorsXLRInput sensitivity-2 dBu/+4 dBuProcessor sectionProtectionsThermalLimiterSoft LimiterControlsVolume, Polarity, Low pass filter frequencyPower sectionTotal Power2200 W PeakCoolingConvectionConnectionsVDEStandard complianceSafety agencyCE compliantPhysical specificationsCabinet/Case MaterialBaltic birch plywoodHandles2 sidePole mount/CapM20 threadGrilleSteelColorBlackSize / WeightHeight693 mm / 27.28 inchesWidth505 mm / 19.88 inchesDepth685 mm / 26.97 inchesWeight44.5 kg / 98.11 lbsShipping informationPackage Height735 mm / 28.94 inchesPackage Width745 mm / 29.33 inchesPackage Depth565 mm / 22.24 inchesPackage Weight51 kg / 112.44 lbs
