Zoom MS-90LP+ Multistomp Looper Pedal
The MS-90LP+ is a serious looping pedal in a compact size, designed to make every step legendary. With the tap of your foot, you can add loops, layers, effects, and rhythm patterns with flawless 32-bit float audio quality.
Key Features
- Five dedicated footswitches for easy control including UNDO, STOP, LOOP FX, and RHYTHM switches.
- Advanced analog circuitry with flat phase response and dual AD converters for clear, high-quality sound.
- 90 minutes of recording per loop and 13 hours total loop storage capacity with up to 100 loops.
- Eight LOOP FX including REVERSE, HALF SPEED, HOLD, and TAPE STOP to add depth and drama.
- 160×128 dot-matrix LCD with color backlight for real-time waveform display and loop status.
- Quantize feature to keep loops and rhythm patterns perfectly in time.
- 68 rhythm patterns with RHYTHM SYNC to start and stop rhythm and loops simultaneously.
- MIDI IN/OUT jacks for external control and syncing with band metronomes.
- USB 2.0 Type-C port for easy importing and exporting of loops and backing tracks.
- Stereo inputs and outputs for guitars, basses, synthesizers, samplers, and keyboards.
- Battery powered with AC adapter, USB battery, or 2 AA batteries for up to 4 hours of use.
Specifications
| Number of memories | 100 |
| Sampling frequency | 44.1 kHz |
| Signal processing | 32-bit float |
| Recording and playback tracks | 1 |
| Data format | WAV (44.1 kHz, stereo, 32-bit floating point) |
| Maximum recording times | 90 minutes (1 loop) / 13 hours total |
| Frequency response | 20 Hz – 20 kHz (+0.5 dB/-0.5 dB) |
| Display | 160×128 dot-matrix LCD with color backlight |
| Inputs | Standard mono phone jacks (L/R), Rated input level: -20 dBu, Input impedance (line): 470 kΩ |
| Outputs | Standard mono phone jacks (L/R), Maximum output level: +7.2 dBu |
| MIDI IN/OUT jacks | Stereo mini jack |
| Input S/N | 122 dB |
| Noise floor | -100 dBu |
| Power | AC adapter 9V DC 500mA center negative (ZOOM AD-16), 2 AA batteries (Alkaline, Lithium or NiMH), USB bus power supported |
| Battery operation times | Alkaline: 4 hours, NiMH: 5 hours, Lithium: 9 hours (approximate) |
| USB | USB 2.0 Type-C, USB MIDI Full Speed, File transfer USB 2.0 High Speed |
| Dimensions | 133 mm (D) x 79 mm (W) x 61 mm (H) |
| Weight | 1 lb (approx. 367 g excluding batteries) |
For more information, visit the official Zoom website.
