Zoom MS-80IR+ Multistomp Multilayer IR Pedal
The Zoom MS-80IR+ MultiStomp pedal is designed for guitarists seeking a versatile and powerful multi-effects processor. Featuring 23 amp and cabinet models developed with advanced Multi-Layer IR technology, it combines three impulse responses recorded at different volumes to authentically recreate the sound and feel of playing through classic amps and cabinets.
Key Features
- 23 guitar amp and cabinet models including 16 classic amps and 7 Zoom originals
- Innovative Multi-Layer IR technology for authentic amp and cab simulation
- 5 studio sound effects to add natural ambience, including Concert Woody Studio and Urban Studio
- 12 essential effects such as noise gates, EQs, and delays
- Create and save up to 80 unique memory patches
- Stereo input and output jacks supporting active and passive instruments
- Output splitting to send signals with and without IRs simultaneously
- Onboard chromatic tuner supporting all standard and alternate tunings
- 2-in/2-out USB-C audio interface for recording and playing along with songs
- Runs on 2 AA batteries or AC adapter with USB bus power support
- Compact and durable pedal design with intuitive control knobs and footswitches
Specifications
| Maximum simultaneous effects | 1 amplifier, 1 studio ambience, 1 other effect |
| User patch memories | 80 |
| Sampling frequency | 44.1 kHz |
| A/D conversion | 24-bit 128× oversampling |
| D/A conversion | 24-bit 128× oversampling |
| Signal processing | 32-bit |
| Frequency response | 20 Hz – 20 kHz (+0.5 dB/-0.5 dB) (when 10kΩ load) |
| Display | 160×128 dot-matrix LCD |
| Inputs | Standard mono phone jacks (L/R), rated input level: −20 dBu, input impedance (line): 470 kΩ |
| Outputs | Standard stereo phone jacks (L/MONO/headphone, R), max output levels vary |
| Input S/N | 122 dB |
| Noise floor | –100 dBu (L/R) |
| Power | AC adapter 9V DC 500mA center negative (ZOOM AD-16), 2 AA batteries (alkaline, lithium, NiMH), USB bus power supported |
| Battery operation times | Alkaline: ~3.5 hours, NiMH: ~4 hours, Lithium: ~7.5 hours |
| USB | USB 2.0 Type-C, data transfer and audio interface support |
| Dimensions | 133 mm (D) × 79 mm (W) × 61 mm (H) |
| Weight | 1 lb (approx. 369 g excluding batteries) |
For guitarists looking to expand their tonal palette, the Zoom MS-80IR+ offers a compact, feature-rich multi-effects pedal with authentic amp modeling and flexible connectivity options. It is ideal for both stage and studio use, with easy patch management and a robust build.
