Zoom MS-70CDR MultiStomp Chorus / Delay / Reverb Pedal
The Zoom MS-70CDR MultiStomp pedal combines the power of a rack-mounted multi-effects device in a compact stompbox. It features 86 custom guitar and bass effects including chorus, delay, and reverb, with up to 6 effects used simultaneously in any order. The pedal includes 50 patch memories, 40 preset patches, an onboard chromatic tuner supporting various guitar and bass tunings, and a Tap Tempo feature for real-time delay and modulation synchronization.
Key Features
- 86 guitar and bass effects including modulation, equalization, delay, and reverb
- Use up to 6 effects simultaneously and arrange them in any order
- 50 memory locations for user-created patches and 40 preset patches
- Onboard chromatic tuner with support for standard and drop tunings
- Tap Tempo for syncing delay times and modulation rates
- Mono and stereo operation with dual 1/4″ input and output jacks
- Backlit LCD display with contrast control
- Runs on 2 AA batteries with up to 7 hours of alkaline battery life or via optional AC adapter
- Lightweight and compact design for easy integration into pedalboards
Specifications
- Sampling frequency: 44.1 kHz
- A/D and D/A conversion: 24-bit, 128x oversampling
- Signal processing: 32-bit floating point and 32-bit fixed point
- Frequency response: 20 Hz – 20 kHz +1 dB, -3 dB (into 10 kΩ load)
- Input impedance: 1 MΩ
- Maximum output level: +5 dBm
- Battery type: 2 x AA size (LR6)
- Battery life: Up to 7 hours with alkaline batteries
- Dimensions: 130.3 (D) x 77.5 (W) x 58.5 (H) mm
- Weight: 350 g (without batteries)
For more information, visit the official Zoom website at zoomcorp.com.
