The HDL6-A is the ideal choice when line array performance isneeded and a fast and easy set-up a must.
RCF HDL6-A overview
The black HDL 6-A Active Line Array Module from RCF is a 2-wayactive line array module designed for live sound reinforcement andinstalled sound applications. Powered by a 1400W 2-channel class-Damplifier, it features two 6″ neodymium woofers for a solid bassreproduction and a 1.7″ voice coil compression driver mounted on aprecise 100 x 10° waveguide. The powerful DSP processes the soundincluding crossover, phase correction, limiting, and protection.The system accept female XLR input connectors and line-levelsignals from a mixing console or other signal source. The outputXLR male connector provides a loop-trough for speaker’s daisychaining. The volume knob controls the volume of the poweramplifier. The control ranges from maximum attenuation to themaximum level (maximum output).
- Equipped with two aluminum rear handles for portability
- Features RCF transducers
- Integrated mechanics are both fast and reconfigurable, allowingthe system engineer to create J-shaped or spiral arrays
- Wooden reinforced composite polypropylene enclosure
- Integrated processing and cabling reduction
- Digital amplifier with switch mode power supply and DSPcontrolled input section with selectable presets
- Powered by a 1400W peak power digital amplifier, split 400W forthe HF, and 1000W for the LF
- HF projection is adjusted by the button on the rear of thecabinets
- 2.0″ inside-outside voice coil
- Water-resistant fiber doped cone
- Polycotton M-roll surround
- High-power magnetic structure
- Inside/outside coil doubles the dissipation surface
- Adhesion area to the former is doubled
- ND 340 high-power compression driver
- 1.7″ voice coil with a crossover point of 900 Hz
- Coverage and dispersion control
- Edge wound voice coils
- Linear frequency response and maximum SPL output
RCF HDL6-A specs:
- Acoustic Specifications
- Frequency Response (-3 dB) 65 Hz to 20 kHz
- Maximum SPL 131 dB
- Horizontal Coverage Angle 100°
- Vertical Coverage Angle 10° maximum
- Compression Driver 1.0″ (2.5 cm) neo, 1.7″ (4.3 cm) voicecoil
- Woofer 2 x 6″ (15.2 cm) neo, 2.0″ (5.1 cm) voice coil
- Input
- Input Connectors XLR male
- Output Connectors XLR female
- Input Sensitivity +4 dBu
- Power Indicators Power cord is connected and the power switchis turned on this indicator lights green
- Signal Indicator Signal indicator lights green if there issignal present on the main XLR input
- Limiter Built-in limiter circuit to prevent clipping of theamplifiers or overdriving the transducers
- Processor
- Crossover Frequencies 900 Hz
- Protection Thermal, RMS
- Limiter Soft limiter
- Controls HF correction
- Amplifier
- Peak Power Total: 1400 W
- High Frequencies: 400 W
- Low Frequencies: 1000 W
- RMS Power Total: 700 W
- High Frequencies: 200 W
- Low Frequencies: 500 W
- Cooling Convection
- Connection VDE connector in
- Physical
- Hardware Array fittings
- Cabinet Composite PP
- Handles 2 back
- Dimensions 9.3 x 18.5 x 15″ (23.7 x 47 x 37.7 cm)
- Weight 25.4 lb (11.5 kg)
The system features state-of-the-art RCF transducers – two powerful6.0″ woofers for a solid bass reproduction plus a high powered 1.7″voice coil compression driver mounted on a precise 100° x 10°waveguide delivers vocal clarity with high definition and anincredible dynamic.
