Qsc Plx1602 Power Amplifier-USED
Sale!

Qsc Plx1602 Power Amplifier-USED

Original price was: $550.00.Current price is: $110.00.

SKU: PLX1602 Category: Tag:

FEATURES:

  • Exclusive PowerWave power supply for superior bass and lighter weight
  • Ultra-low distortion (0.03% THD at 8 ohms) & studio-quality noise floor (-107 dB)
  • LED indicators include bridge mono and parallel input modes
  • Compact 2 RU, 21 lbs. and 13″ deep chassis fits into any rack
  • Selectable clip limiters and subsonic filters reduce distortion and protect speakers
  • Variable-speed fan for low noise and solid 2 ohm performance
  • Both 1/4″ TRS & XLR inputs, Speakonª and shock-proof binding post outputs
  • 3-year warranty plus optional 3-year extension available

    SPECIFICATIONS:

    WATTS STEREO MODE

  • 8 ohms 20 Hz-20kHz 0.03%THD-300W
  • 4 ohms 20 Hz-20kHz 0.05%THD-500W
  • 2 ohms 1kHz 1%THD-800W
  • BRIDGE MONO MODE
  • 4 ohms 1kHz 1%THD-1600W
  • Distortion (SMPTE-IM) Less than 0.01%
  • Distortion (typical) 20 Hz-20 KHz: 10 dB below rated power 1.0 kHz and below: full rated power Less than 0.01% THD
  • Frequency Response 20 Hz-20 kHz, ± 0.2 dB/8 Hz-50 kHz, +0, -3 dB
  • Damping Factor greater than 500 Input Impedance 6 K ohms unbalanced, 12 K ohms balanced Input Clipping 10 Vrms (+22dB) Cooling Variable-speed fan, rear-to-front air flow Connectors (each channel) Input: 3-pin XLR and 1/4″ TRS balanced Output: Neutrik Speakon and touch-proof binding posts Amplifier Protection Full short circuit, open circuit, thermal, ultrasonic, & protection. Stable into reactive or mismatched loads. Load Protection On/off muting, DC-fault power supply shutdown Dimensions 19″ (48.3cm) rack mounting, 3.5″ (8.9 cm) tall (2 rack spaces), 13.25″ (33.7 cm) deep (from front mounting rails) Gain 40x (32 dB) Weight 21 lb (9.5 kg) net
